Best Quality Automotive Carbon Cleaner With Anti-fireback System
100 % Safety
Operation Instruction:
1. Connect the outlet pipe of the equipment to the vacuum pipe of
the vehicle (For vehicles without vacuum pipe, insert the outlet
pipe directly from the air filter to the engine inlet pipe)
2. Start the vehicle at idle
3. Turn on the equipment power and select the corresponding exhaust
volume through the touch screen
4. Select negative pressure mode or vibration mode, and click the
start button to start carbon removal
5. After 30 minutes of decarbonization, the device will alarm,
indicating that the decarburization is completed and the equipment
will automatically stop gas production
6. After waiting for about 1 minute, turn off the engine and resume
the automobile pipeline.
7. Restart the vehicle
8. Step on the accelerator at a constant speed to a rotating speed
of 3,000-3500 RPM and then release, and then step on it at an
interval of 3 seconds. Repeat this for 8 ~ 10 times to expel the
water and dirt in the exhaust pipe and end the carbon removal
Applicable to all models and all related car engine system parts
Specific Parameter/Configuration
Electrical Characteristics
Rated Voltage: AC 220V 50/60Hz
Max Power: 4.5KW
Max Gas Output: 1500L/H±10%
Max Working Pressure: ≤2 Kg/cm2
Electrolyte consumption: ≤240g/H
Water Tank Capacity: 17L
Working Ambient: 5℃～45℃
Product Configuration:
1. Power Supply: IGBT Power Supply System
2. Overpressure Protection:Pressure Sensor and Pressure Transmitter
3. Anti-backfire system: Industry Multi-function Dry Anti-backfire
System
4. Electrolyte Level Protection: High and Low Liquid Level Sensor
5. Overtemperature Protection:Temperature Sensor
6. Integrated Electrolytic Cell: Anti-explosion and Anti-leakage
7. Moisture Separation: Moisture Separator
8. LCD Touch Screen: 7.0Inch
Differences between hho and other machines:
| Hho carbon cleaner | Chemicals drip carbon cleaner | Water based foam detachable | Traditional dismantle engine |
| Carbon cleaning time | 20 minutes | 40 minutes | 40 minutes | About 2 to 4 hours |
| Environmental protection | Complete combustion, non-toxic and harmless exhaust | Toxic and harmful exhaust | Not easy to handle waste | Carbon particles, not easy to handle waste |
| Advantages and disadvantages | The engine can be idling | The engine is running at idle speed, and the medicament is
continuously inhaled | The implementation process is cumbersome and the carbon is
incomplete | Time wasting, destroying the original assembly, cleaning intuitive |
| Cost | Carbon cleaning process | Chemicals drip, engine oil, oil filters | Chemicals foam, engine oil, oil filters | Time of engine dismantling, chemical drip, engine oil, oil filters |
HHO working principle:
The equipment generates hydrogen and oxygen mixed air stream (brown
gas) through electrolysis, which is fed into engine combustion
chamber by engine intake manifold.Brownian gas characteristics such
as hydrogen and oxygen catalysis principle, oxygen-rich combustion
principle and water and hydrogen cycle principle are used to
completely and thoroughly remove engine carbon.Due to hydrogen
combustion generated after water, attached to the internal walls
and makings, dirt on the exhaust pipe inner surface is wet melted
into liquid, and then under the impetus of the exhaust pressure,
out of the car, realized the internal automatic cleaning process,
and will not cause any damage to the engine, make up for the
deficiency of the traditional chemical carbon removal.
